Ménage Appliances

MRCOOL DIY Multi-Zone 2-Zone 18K BTU Condenser, 4th Gen Series, DIY-MULTI2-18HP230C

MRCOOL DIY Multi-Zone 2-Zone 18K BTU Condenser, 4th Gen Series, DIY-MULTI2-18HP230C

Regular price $1,372.00 USD
Regular price $2,499.99 USD Sale price $1,372.00 USD
Sale Sold out
Shipping calculated at checkout.

Comes with 6 Kitchen Towels for FREE! (Complimentary Items):

View full details

The 4th Generation MRCOOL® DIY 18K BTU 2-Zone Ductless Heat Pump Condenser is the latest in heat pump technology. This 2-zone condenser, when paired with select MrCool air handlers, is capable of producing an impressive 21 SEER efficiency rating. It also has the ability to heat even when temperatures drop to -13°F. It features robust construction which includes a Gold Fin Condenser coating so it is sure to withstand exposure to the elements. For added peace of mind, this is the only condenser on the market that comes with a limited lifetime compressor warranty. As a MrCool DIY product, this heat pump is designed specifically to be used with MrCool’s patented Pre-Charged Quick Connect Line Sets. These line sets come pre-charged with the precise amount of R-410A refrigerant. They are also equipped with quick connectors, so the line set can be connected to the condenser by the homeowner using only wrenches. This means the installation process can be performed without retaining the services of a certified technician. Let the 4th Generation MrCool DIY 18K BTU 2-Zone Ductless Heat Pump Condenser be the solution to your home’s heating and cooling needs.



Features

  • Up to 21 SEER
  • Gold Fin® condenser: corrosion resistant - live on the coast? Don't worry, our condenser is built to resist long term corrosion
  • Energy Efficient DC Inverter
  • R-410A environmentally friendly refrigerant
  • Standard 7-year compressor/5-year parts warranty; register for limited lifetime compressor warranty
  • Line sizes 1/4”, 1/2” & 3/8”, 5/8”
  • Multi-Zone Condenser includes adapter for the 24K Air Handler (3/8", 5/8" Line Size) - see liquid line and suction line size columns

Specifications

EER

21

SEER2

21.2

EER

12.5

EER2

12.5

HSPF-4

10.6

HSPF-5

8.6

CFM

1764.71

COOLING CAPACITY (BTU)

18000

HEATING CAPACITY (BTU)

19000

VOLTAGE (V)

208-230

PHASE

1

CYCLE

60

MAX FUSE BREAKER (A)

25

MIN CIRCUIT AMPACITY (A)

18

COLOR

White

COLOR FAMILY

White

ZONE CAPACITY

2

REFRIGERANT TYPE

R-410A

REFRIGERANT VOLUME (OZ)

65.26

DECIBEL RATING (DBA)

59

INVERTER

Yes

MIN AMBIENT COOL (F)

5 ~ 122

MIN AMBIENT HEAT (F)

-13 ~ 75.2

MAX LINESET LENGTH (FT)

123 TOTAL

LIQUID LINE SIZE

1/4

SUCTION LINE SIZE

1/2

COMPRESSOR MOTOR TYPE

Twin - Rotary

CONDENSER FAN MOTOR RPM

750/600/500

WIFI COMPATIBILITY

Yes

APP COMPATIBILITY

Yes

WORKS WITH IOS

Yes

WORKS WITH ANDROID

Yes

REGISTERED WARRANTY

Limited Lifetime Compressor

BASE WARRANTY

5-year Parts/7-year Compressor

BASE PARTS WARRANTY

5-year Parts

REGISTERED COMPRESSOR WARRANTY

Limited Lifetime Compressor

BASE COMPRESSOR WARRANTY

7-year Compressor

CONTAINS ELECTRONICS

Yes

CONTAINS CHEMICALS

Yes

CONTAINS AEROSOL

Yes

CONTAINS COMPRESSED GAS

Yes

PROPOSITION 65 WARNING

Yes

NET DEPTH (IN)

13.46

NET HEIGHT (IN)

26.50

NET WIDTH (IN)

35.04

NET WEIGHT (LBS)

100.53

GROSS DEPTH (IN)

17.64

GROSS HEIGHT (IN)

29.33

GROSS WIDTH (IN)

40.94

GROSS WEIGHT (LBS)

111



Information & Guides

Brochure

Install Manual

Spec Sheet

Owner Manual

Remote Control Manual

Technical Manual

Service Manual

Warranty Document

Manual De Instalación (En Español)

AHRI Certification

Energy Guide Certs

Multi-Zone Matchups
